KAP Industries Fire Extinguisher Bracket – Toyota Hilux 2015+ (Eighth Generation)

This Fire Extinguisher Bracket fits both drivers side and passenger side of the Toyota Hilux 2015+ (Eighth Generation). Including left hand drive and right hand drive!

Made from 2mm Steel and Powder Coated Black. The bracket has a series of slots so no drilling is required. It’s a 5 minute install!

Installation

1. Mount fire extinguisher holder to the KAP Industries Bracket, using the supplied M5 Bolts.
2. Carefully remove front seat bolts
3. Gently raise the front seat and slide the bracket under the rail, lining up the bolt holes.
4. Replace Bolts and hand thread into position
5. Gradually tighten each bolt

Kit Contents

• 1 x Toyota Hilux 2015+ (Eighth Generation) Bracket
• 2 x M5 Stainless Nylocks
• 2 x M5 Stainless Hex Bolts

NOTE: Seat bolts are easily cross threaded. Please be careful during removal and installation.
